2ft 100W LED I-Beam High Bay(347V)

MX899HLX10022BKKDXW

Brandon industrial 2ft 100W high bay led retrofit is an ideal one-to-one replacement for conventional HID and fluorescent lighting systems in large indoor spaces, including manufacturing, warehousing, commercial, and gymnasium applications with mounting heights ranging from 10 ft.to 45 ft.

This mini size family of linear LED linear high bay led retrofits incorporates four different fixtures including 100,150,200 and 300 Watt high bay models. The product come with LPW of 155.

Construction:

  • Heavy gauge steel body with welded frame construction resists twisting and bowing

  • White polyester powder-coat finish

  • Integrated frosted polycarbonate diffuser lens reduced glare and remains high efficacy

  • Large wiring compartment and multiple knock-outs to accommodate lighting controls

Certification:

  • UL listed for damp location

  • RoHS Compliant

  • DesignLights Consortium® Premium Qualified

Applications:

  • Convention Centers
  • Big Box
  • Retailers
  • Packaging Facilities
  • Distribution Centers
  • Manufacturing Plants
  • Warehouse Lighting
  • Factory Lighting
  • Gymnasium Lighting
  • LED Shop Lights
  • Transit Facilities

Dimension: 24 2/8x13x2″ | 615*330*50mm

Electrical:

  • Wattage: 100W
  • Efficacy: 155LPW
  • Lumens: 15,500lm
  • Voltage: 347V AC
  • CCT: 4000K, 5000K, 5700K
  • CRI: 82
  • PF: >0.92
  • THD: <15
  • Dimming: 0-10V DC
  • Frequency:50/60Hz
  • Class P LED driver

Feature:

  • Saves 45% energy compared with HID
  • High-output LEDs and optics
  • Uniform light levels for visual comfort
  • Easy to maintain
  • Flexible mounting option
  • Designed for easy replacement of light engines and drivers
  • Flexibility in design and installation
  • Rebates&Incentives

Options:

  • Battery Backup

  • Bi-level sensor(extegrated)

  • Suspension Chain

  • Surface mount kits

50K

At 10 hours daily use, BRANDON LEDs are rated to last 13 years, dramatically reducing maintenance and re-lamping cost

5Years

The BRANDON 5-year, limited warranty covers light output and driver performance

0-10V

0-10V is our standard and LED driver inventory we keep for most products. Other dimming are available but longer lead time.

WATTS

100W|150W|200W|300W

CCT

3000K-6500K

EFFICIENCY

155LPW

LENGTH

2FT/4FT

The Guide to Choose the Correct High Bay

10-15 feet

This height is ideal for lights with 10,000 to 15,000 lumens

15-20 feet

This height is ideal for lights with 16,000 to 20,000 lumens

25-30 feet

For this height, lights with 33,000 lumens are ideal
