Key Features:

💡 High Efficiency – Up to 130lm/W LED performance

⚙️ Versatile Design – Up, down, or bi-directional light distribution

🧱 Durable Build – Aluminum(steel) housing with powder coating

🎨 Custom Finish – Available in white, black, or silver

🔌 Easy Installation – Surface-mounted wall bracket system

🏢 Wide Applications – Ideal for offices, hotels, and residential interiors

Applications:

• Hotel corridors and guest rooms

• Office walls and meeting spaces

• Residential living areas and staircases

• Retail and hospitality environments

✅ Product Options

Our Wall Mounted Linear Light Fixture is designed with flexible configurations to meet different lighting needs for offices, hotels, corridors, and other interior spaces.

📏 Length Options: Available in 2ft / 4ft / 8ft sizes for various wall layouts.

🔆 Beam Angle: Wide 120° distribution for smooth, uniform wall illumination.

⬇️ Light Direction: Choose Up, Down, or Up-Down lighting for design flexibility.

🌈 CCT Selectable: Easily switch between 3000K / 4000K / 5000K color temperatures.

⚙️ Field-Selectable Wattage: Adjustable power output for optimized energy use.

🚶 Integrated Motion Sensor: Automatically activates lighting when movement is detected.

🔋 Built-in Battery Backup: Ensures illumination during power interruptions.

✅ UL Listed for Damp Locations: Safe and reliable performance in semi-moist environments such as bathrooms or corridors.

💬 Frequently Asked Questions—Wall-Mounted Linear Light Fixtures

1. What is a wall mounted linear luminaire?

A wall mounted linear luminaire is a rectangular or elongated LED fixture designed to be mounted along walls to provide direct, indirect, or combined illumination. It creates a clean, architectural lighting line ideal for corridors, stair cores, offices, and public spaces.

2. What are the main advantages of wall mounted linear lighting?

These fixtures provide uniform brightness, low glare, and a modern aesthetic. They enhance vertical illumination, save ceiling space, and can serve as both accent and functional lighting in commercial and residential interiors.

3. What widths and lengths are available?

Standard widths include 1.5″, 2″, 2.75″, 4″, and 6″, while lengths range from 2ft to 8ft. Custom lengths can also be ordered to create continuous runs or tailored spans that align with wall geometry and ceiling height.

4. Can these luminaires be installed in continuous rows or corners?

Yes. Many families support continuous run installation using seamless joiners and corner connectors, allowing smooth light lines around walls or across stairwell turns.

5. What lighting options does this family offer?

You can choose between down light, up light, and up-and-down configurations to achieve layered lighting — ideal for wall washing, accenting architectural features, or general illumination.

6. What beam angles are available?

Typical beam angles include 60°, 90°, and 120°, with wide-beam wall-washer optics available for smooth vertical lighting on wall surfaces.

7. What are the key design features?

Fixtures feature minimalist rectangular profiles, concealed fasteners, and precision optics. They ensure uniform luminance, glare control, and long-term thermal performance while blending seamlessly with modern interiors.

8. What materials are used in wall mounted luminaires?

Most models use extruded aluminum(or robust steel) housings for excellent heat dissipation and durability, paired with acrylic or polycarbonate diffusers that provide soft, even illumination.

9. What finishes are available?

Finishes include matte powder coatings, anodized trims, and neutral tones (white, black, silver) that coordinate with materials like metal, stone, glass, or wood. Custom RAL colors can be specified for branded interiors.

10. Are these luminaires suitable for healthcare or institutional environments?

Yes. Overbed and hospital wall luminaires support high CRI, precise color temperatures, dimming, and emergency operation. They meet requirements for healthcare, lab, or educational applications.

11. Are stairwell or corner-mounted wall luminaires available?

Yes. Corner or stairwell luminaires are designed for safety and efficiency, offering occupancy sensors, emergency battery backup, and wide beam coverage for egress and circulation areas.

12. Can these fixtures be used outdoors?

Certain models, such as cylinder wall mounted lights, are rated IP65 or higher, making them suitable for building exteriors, entrances, and pathways with full weather protection.

13. How energy-efficient are these wall mounted linear fixtures?

They use high-efficiency LED chips and optimized drivers, achieving up to 130–150 lm/W. Optional occupancy sensors, daylight dimming, and field-selectable wattage further reduce energy consumption.

14. What control and sensor options are available?

Fixtures can integrate 0–10V or DALI dimming, motion sensors, daylight harvesting, Bluetooth control, or smart building system compatibility for automated lighting management.

15. What certifications and standards apply?

Models are typically UL or ETL listed for damp locations, meeting NFPA 101, CEC, or IEC 60598 safety standards. Outdoor types comply with IP65/IK08 ratings for durability and weather resistance.

16. Can wall mounted luminaires be customized?

Absolutely. Customization options include length, finish color, beam angle, mounting type (surface or recessed), output wattage, and optical control, allowing full flexibility for architectural design.

17. How easy is installation and maintenance?

Fixtures mount directly to walls with standardized brackets and integrated cable management. Modular components simplify both installation and servicing, minimizing downtime and maintenance costs.

18. How do I choose the right color temperature and brightness?

Select 3000K–3500K for warm hospitality spaces, or 3500K–4000K for clear visibility in offices or healthcare areas. Match lumen output to foot-candle requirements and consider up/down or wall-wash effects to balance aesthetics and performance.
